Flow Pack GSP 45 Refurbished

At a glance, what it does

DESCRIPTION

Horizontal Flow Pack GSP 45 automatic packaging machine with rotary sealer.
A simple, compact, essential and very reliable horizontal Flow Pack packaging machine.
Suitable for small products, it is certainly the ideal solution for those who do not have special packaging needs or do not need particularly high packaging speeds.
Thanks to the small variable tunnel it is able to add excellent versatility to simplicity, certainly ideal for those who are entering the world of automatic packaging for the first time or who cannot dedicate different lines to different products.

Flow Pack Packaging Machine

ACCESSORIES INCLUDED

Notch pitch photocell
Variable conformer tunnel
Rotary marker

For each machine

TECHNICAL SPECIFICATIONS

• Max Reel: 420 mm
• Max product: mm 250 x 210 x h40 *
• sealer: 250 mm
• Packaging machine: 4400 x 850 x h1800 mm
• Speed: 30 / 50ppm
* the measures cannot coexist

REQUEST A QUOTE

In detail, what it does

IN-DEPTH DESCRIPTION

Flow Pack GSP 45 automatic with rotary sealer used and reconditioned. Compact horizontal packaging machine, suitable for packaging small products.

Welding on the bottom of the product

This type of flow pack packaging machine carries out a sealing at the top and at the end of the package thanks to the transversal sealer and a longitudinal seal under the product along the entire length. The result obtained is the typical flow pack that we are used to seeing in brioches.

Rotary sealer

The rotary sealer is the most common type of sealer in flow pack packaging machines. It is a sealer composed of two spatulas fixed on two pins that rotate synchronously and which meet only once for each rotation. This type of welding allows for high packaging speeds with minimal cost technical equipment.
It is also possible to increase the packaging capacity by inserting an additional (or more) pair of spatulas to double or quadruple the speed. This option can almost never be implemented on existing machines but is very often used in the design phase of the flow pack packaging machine.

Notch pitch photocell for printed film

A device for reading the printed film notch pitch that allows you to read the position of the notch and to correct the phasing of the envelope so that the sealing always takes place between one notch and another. This method is essential if the package we have to make is printed with a graphic that must always be shown in full.

Many brands to choose from

GSP

GENERAL SYSTEM PACK. The company's aim has always been to meet the needs of packaging in all its forms with its wide range of products in which it also designs packaging machines for snacks.
With over 25 years of experience in the packaging sector, it produces a wide range of snack packaging machines, all designed with modern technologies that make them versatile and easy to handle, suitable for packaging a wide range of products.

A BIT OF HISTORY

For almost thirty years GSP has been designing, manufacturing and supplying packaging machines and automatic packaging systems, thanks to a dynamic team of professionals who are enthusiastic about their work.

Among the pages, the documentation

DOCUMENTATION

You can download the technical documentation of the packaging machine by clicking on the link below.
A page will open asking you for an authentication password.
To get the password, fill out the form on the side and we will contact you to provide you with all the documentation you need (if we have it).
